TC-1193-X带灯轻触开关6*6




LED颜色种类:蓝色、红色、黄色、绿色、橙色、双色等。

基本参数

 1.额定范围Rating: 50mA 12VDC

2.接触电阻Contact Resistance : 50mΩ max(initial)

3.绝缘电阻Insulation Resistance: 100MΩ(minDC 250V)

4.耐压强度Dielectric Strength : AC250V(50/60Hz for 1minute)

5.机械寿命Electrically Life:100,000cycles

6.环境温度Environment temperature: -25℃~+105℃

7.操作力度Operating Force: 180/250(±30gf)
