TC-1209-X带灯轻触开关





基本参数
	1.额定范围Rating: DC 12V 50mA 2.接触电阻Contact Resistance : ≤50MΩ 3.绝缘电阻Insulation Resistance: ≥100MΩ 4.耐压强度Dielectric Strength : AC 250V 1minute 5.操作力度Operating Force: 180±50gf or 250±50gf 6.机械寿命Electrically Life:≥100,000cycles
